Supermicro SuperStorage SSG-2029P-E1CR24L

The Supermicro SuperStorage SSG-2029P-E1CR24L is a high-density 2U storage server designed for demanding, I/O-intensive environments. It combines dual-socket compute performance with extensive hot-swap storage capacity and highly efficient, redundant power.

Key platform specifications

• Socket / CPU support: LGA 3647, dual-socket design for 1st/2nd Gen Intel Xeon Scalable processors
• Max CPU TDP: up to 205 W per processor
• Memory architecture: 16 DIMM slots, up to 4 TB 3DS ECC DDR4-2933 RDIMM/LRDIMM
• Form factor: 2U rackmount chassis

Storage subsystem

• Drive bays: 24x 2.5" front-access hot-swap bays
• Drive interfaces: SAS and SATA support, plus 4x NVMe-enabled bays
• Hot-swap capability: all 24 bays designed for serviceability and fast replacement

Expansion and connectivity

• PCIe slots: 3x PCI-E 3.0 x16 and 4x PCI-E 3.0 x8 for HBAs, RAID, network or accelerator cards
• Network interfaces: 2x RJ-45 10 Gb/s ports for high-bandwidth connectivity
• USB ports: 5x USB 3.0 (4x rear, 1x internal Type-A)
• M.2 NVMe: no onboard M.2 NVMe slots

Power and reliability

• Power supplies: 2x 1200 W redundant units for continuous operation
• Efficiency: 80 Plus Titanium certification for optimized power usage and reduced heat output
• Redundancy: redundant power design to minimize downtime risk
• Warranty: 36-month manufacturer warranty

Operational benefits

• High memory and core density support for consolidation of storage and compute workloads
• Flexible storage configuration with SAS, SATA and NVMe support in a compact 2U chassis
• 10 GbE connectivity and multiple PCIe slots for building high-throughput storage or virtualization platforms
• Redundant, high-efficiency power delivery designed for data center and mission-critical deployments
