Supermicro SYS-F618R2-RTPT+

The Supermicro SYS-F618R2-RTPT+ is a high-density 4U server platform engineered for compute- and memory-intensive workloads. It integrates dual LGA 2011 sockets for Intel Xeon E5-2600 v3/v4 processors with a maximum TDP of 145W, delivering scalable performance in data center and enterprise environments.

Compute and memory subsystem

• Socket: LGA 2011 with dual-processor support (Intel Xeon E5-2600 v3/v4 family)
• Maximum CPU TDP: 145W per processor, enabling deployment of higher-core SKUs within the supported range
• 16 DIMM slots for DDR4 memory
• Maximum memory capacity: up to 2TB ECC 3DS LRDIMM or up to 1TB ECC RDIMM
• Memory speed support up to DDR4-2400 MHz (depending on CPU and module configuration)

Storage and expansion

• Drive bays: 6x 2.5" hot-swap bays for SATA/SAS drives
• Main/optional drive interface: SATA/SAS (controller-dependent)
• PCIe expansion: 1x PCI-E 3.0 x16 Low Profile, 1x PCI-E 3.0 x8 MicroLP
• M.2 NVMe slots: 0 (no onboard M.2 NVMe interface specified)

Networking and connectivity

• Network interfaces: 2x RJ-45 10Gb/s ports for high-throughput Ethernet connectivity
• USB: 2x USB 3.0 ports (rear) for external devices, service, and maintenance

Power and reliability

• Power supply capacity: 1620W total
• Number of power supplies: 4, configured as redundant for high availability
• Redundant power: Yes, designed to maintain operation in case of PSU failure
• Energy efficiency: 80 Plus Platinum, supporting reduced power losses and improved power usage effectiveness
• Chassis form factor: 4U rackmount, suitable for standard rack deployments
• Manufacturer warranty: 36 months (subject to vendor terms and conditions)

Operational advantages

• High memory density and ECC support help maintain data integrity in demanding, always-on environments.
• Dual 10GbE interfaces provide bandwidth headroom for virtualization, storage, and clustered applications.
• Redundant, high-efficiency power architecture supports continuous operation and helps minimize downtime risk.
• Hot-swap 2.5" bays facilitate drive replacement and capacity scaling without planned service interruption.
