Supermicro Superstorage SSG-2029P-E1CR48H

The Supermicro Superstorage SSG-2029P-E1CR48H is a high-density 2U storage platform engineered for demanding, scale-out and enterprise storage workloads. It combines dual-socket compute performance with very high 2.5" drive capacity and enterprise-grade power efficiency.

Compute and memory platform

• Socket: LGA 3647 with support for 1st and 2nd Gen Intel Xeon Scalable processors
• Dual CPU sockets for balanced performance and scalability
• Max. CPU TDP: up to 165 W per processor
• 24 DIMM slots for high memory density configurations
• Maximum memory: up to 6 TB 3DS ECC RDIMM/LRDIMM DDR4-2933 MHz

High-density storage subsystem

• 2U rackmount chassis optimized for storage capacity
• Drive bays: 48x 2.5" hot-swap bays
• Drive interfaces: SAS3 + SATA3 (main), enabling flexible media choice
• Integrated RAID controller installed in a PCI-E 3.0 x8 x8 slot

Expansion and connectivity

• PCIe slots: 2x PCI-E 3.0 x16, 1x PCI-E 3.0 x8, 1x PCI-E 3.0 x8 x8 (with RAID controller)
• USB: 3x USB 3.0 (2x rear, 1x internal Type A)
• Networking: connectivity available via optional SIOM card (SIOM-ready design)
• M.2 NVMe slots: 0

Power and reliability

• Power supply: 2x 1600 W redundant units
• Energy efficiency: 80 Plus Titanium certification
• Redundant power design for high availability environments
• Manufacturer warranty: 36 months

Usage considerations

• Suitable for scenarios requiring very high 2.5" drive density and dual-socket compute
• Designed for environments where power efficiency and redundancy are critical
• Flexible PCIe and SIOM options allow tailoring connectivity to specific infrastructure requirements
