Supermicro MBD-X10DRD-INT Motherboard

The Supermicro MBD-X10DRD-INT is a server-grade E-ATX motherboard engineered for dual-socket Intel Xeon E5-2600 v3/v4 platforms. It targets environments that require high memory capacity, reliable 24/7 operation and scalable I/O throughput.

Processor and socket support

• Socket type: LGA 2011
• CPU support: Intel Xeon E5-2600 v3/v4 family
• Number of CPU sockets: 2 (dual-socket configuration)
• Maximum supported CPU TDP: 145 W
• CPU included: not included

This configuration enables multi-core, multi-threaded workloads and is suitable for compute-intensive server roles when paired with compatible Xeon processors.

Memory subsystem

• Number of DIMM slots: 8
• Maximum memory capacity: up to 1 TB
• Memory type: ECC 3DS LRDIMM DDR4
• Supported memory speed: up to 2400 MHz

The platform is optimized for high-capacity ECC memory configurations, which helps improve data integrity and system stability in virtualized, database or analytical workloads.

Expansion and connectivity

• PCIe expansion: 4 x PCI Express 3.0 x8
• USB ports: 7 x USB 2.0 (4 rear panel, 2 optional, 1 internal Type A)
• Network interfaces: 2 x RJ-45 10 Gb/s
• M.2 NVMe slots: 0

The PCIe 3.0 x8 slots provide flexibility for add-in cards such as storage controllers, additional network adapters or accelerator cards, depending on system design. Dual 10 GbE ports support high-throughput networking in data center and enterprise environments.

Form factor and integration

• Motherboard form factor: E-ATX
• Intended usage: rack or tower servers compatible with E-ATX boards

The E-ATX layout enables integration into standard server chassis that support extended ATX form factor, allowing dense component placement and robust airflow design.

Reliability and warranty

• Manufacturer warranty: 36 months

The 3-year manufacturer warranty provides a defined support horizon for long-term server deployments.

This motherboard is suitable for technical users and integrators building dual-socket Xeon servers where high memory capacity, 10 GbE connectivity and flexible PCIe expansion are required. Storage configuration, cooling, power delivery and additional features depend on the selected chassis and optional components.
