Supermicro MBD-X11SRM-VF Motherboard

The Supermicro MBD-X11SRM-VF is a microATX server/workstation motherboard designed for professional workloads that require high reliability, ECC memory support and flexible expansion in a compact form factor. It is built around the LGA 2066 socket and supports Intel Xeon W-2100/2200 processors with a maximum TDP of 165 W.

Key technical specifications

• Processor socket: LGA 2066
• CPU support: Intel Xeon W-2100 / W-2200 family
• Number of CPU sockets: Single
• Max. CPU TDP: 165 W
• Form factor: microATX

Memory subsystem

• Memory slots: 4 DIMM slots
• Supported memory types: ECC LRDIMM, ECC RDIMM
• Maximum capacity: up to 512 GB ECC LRDIMM; up to 256 GB ECC RDIMM
• Memory speed: DDR4-2133 MHz

Expansion and storage

• PCI Express slots:
• 1 × PCIe 3.0 x16
• 2 × PCIe 3.0 x8
• M.2 NVMe: 1 × M.2 slot for NVMe SSD (high-speed OS or application drive)

Networking and connectivity

• LAN interfaces: 2 × RJ-45, 1 Gb/s
• USB ports: 6 × USB 2.0 (2 rear, 4 optional)
• 5 × USB 3.0 (2 rear, 1 Type-A, 2 optional)

Operational advantages

• High memory capacity: Up to 512 GB ECC LRDIMM enables consolidation of memory-intensive workloads on a single system.
• Data integrity: ECC LRDIMM/RDIMM support reduces the risk of memory-related errors in continuous 24/7 operation.
• Flexible expansion: Three PCIe 3.0 slots allow integration of professional GPUs, RAID controllers or additional network adapters.
• Compact design: microATX form factor facilitates deployment in smaller chassis and dense environments.
• Fast storage: M.2 NVMe slot provides low-latency access for system and application data.

Reliability

• Manufacturer warranty: 36 months

The Supermicro MBD-X11SRM-VF is suitable for professional use cases that demand a stable platform with ECC memory, robust I/O and long-term availability, such as engineering workstations, small servers, and specialized industrial or laboratory systems.
