Supermicro MBD-X11SSV-M4F Motherboard with Intel Xeon E3-1585 v5

Supermicro MBD-X11SSV-M4F is a Mini-ITX motherboard with an integrated Intel Xeon E3-1585 v5 processor, engineered for compact, reliable and compute-intensive deployments. With server-class components and ECC memory support, it is suitable for applications where stability and data integrity are critical.

Key hardware specifications

• Socket / CPU: FCBGA1440 with onboard Intel Xeon E3-1585 v5, 4 cores / 8 threads, 3.5 GHz base clock, 65 W TDP
• CPU count: Single processor, 1 integrated CPU included
• Form factor: Mini-ITX for space-constrained chassis and embedded systems
• Memory: 2x SO-DIMM slots, up to 32 GB ECC DDR4-2133 MHz
• Expansion: 1x PCI Express 3.0 x16 slot for GPU, RAID, or high-speed I/O cards
• Storage: 1x M.2 NVMe slot for high-performance SSD integration
• Networking: 4x RJ-45 1 Gb/s LAN ports for multi-network, redundancy or link aggregation scenarios
• USB connectivity: 5x USB 2.0 (4 via internal header, 1 Type-A), 4x USB 3.0 (rear)
• Audio: ALC 888S HD Audio codec for clear, multi-channel audio output
• Warranty: 36-month manufacturer warranty

Operational advantages

• Integrated Xeon platform: Onboard Intel Xeon E3-1585 v5 minimizes compatibility issues and simplifies thermal design by fixing CPU TDP at 65 W.
• ECC memory support: Up to 32 GB ECC DDR4-2133 SO-DIMM enhances data integrity for professional workloads, reducing the risk of memory-related errors.
• High network density: Four 1 GbE ports enable separation of management, storage and client traffic or implementation of fault-tolerant network topologies.
• Compact design: Mini-ITX footprint allows deployment in small enclosures, edge devices or embedded systems without sacrificing expansion via PCIe x16 and M.2 NVMe.
• Extended connectivity: Multiple USB 2.0/3.0 ports and internal headers facilitate integration of peripherals, front-panel I/O and service interfaces.
• Long-term reliability: Server-class design combined with a 36-month warranty supports continuous operation in professional environments.

This platform is intended for users who require a compact, technically robust motherboard with integrated processing power, ECC memory capability and multi-port networking, without compromising on expansion or serviceability.
