Supermicro SuperStorage SSG-6048R-E1CR90L

Supermicro SuperStorage SSG-6048R-E1CR90L is a high-density 4U storage server designed for environments requiring large-capacity, high-availability disk subsystems and robust compute resources. The platform combines dual Intel Xeon E5-2600 v3/v4 processors with enterprise-grade power and connectivity.

Compute and memory architecture

• Socket: LGA 2011 with support for Intel Xeon E5-2600 v3/v4 CPU family
• Processor sockets: Dual-socket configuration for scalable performance
• Memory slots: 8 DIMM slots for DDR4 ECC
• Maximum RAM: up to 1TB using 3DS LRDIMM, or ECC RDIMM DDR4-2400MHz modules (depending on configuration)

High-density storage subsystem

• Form factor: 4U rackmount
• Drive bays: up to 90x hot-swap bays for large-scale storage deployments
• Drive size: native 3.5" support, with optional 2.5" configurations
• Drive interfaces: SAS3 + SATA3 for flexible use of HDDs and SSDs

Network connectivity

• Network ports: 4x SFP+ 10Gb/s for high-throughput data paths

Power and availability

• Power supply: 1000W per PSU
• Number of power supplies: 4 for enhanced power distribution
• Redundancy: redundant power design for higher availability
• Efficiency: 80 Plus Titanium certification for optimized energy usage
• Manufacturer warranty: 36 months

I/O and expansion

• USB ports: 2x USB 3.0 (rear), 4x USB 2.0 (2x rear, 2x optional)
• M.2 NVMe slots: 0

Key technical advantages

• Very high disk density with 90x hot-swap bays for capacity-focused deployments
• Dual-socket Xeon E5-2600 v3/v4 platform for balanced compute and storage workloads
• ECC DDR4 memory support up to 1TB to improve data integrity and system stability
• Redundant, high-efficiency 80 Plus Titanium power supplies to reduce downtime risk and power losses
• Integrated 4x 10GbE SFP+ for fast backend or client connectivity in storage networks
