Supermicro SuperStorage SSG-6029P-E1CR12L

Supermicro SuperStorage SSG-6029P-E1CR12L is a high-density 2U storage server platform designed for demanding, I/O-intensive workloads and scalable enterprise environments. It combines dual-socket compute performance with flexible storage and advanced power efficiency.

Compute platform

• Socket: LGA 3647
• CPU support: 1st / 2nd Gen Intel^® Xeon^® Scalable processors
• Number of CPU sockets: Dual
• Maximum CPU TDP: up to 205 W per processor

Memory subsystem

• RAM slots: 16 DIMM sockets
• Maximum memory capacity: up to 4 TB
• Memory type: 3DS ECC DDR4-2933 RDIMM / LRDIMM
• Error correction: ECC for enhanced reliability and data integrity

Storage configuration

• Form factor: 2U rackmount chassis
• Hot-swap drive bays: 12x front-access bays
• Drive size: 3.5" (optional configuration for 2.5" drives)
• Main disk interface: SAS + SATA
• Optional interface configuration: SAS + SATA + 4x NVMe for performance tiers
• M.2 NVMe slots: 2x M.2 for high-speed OS, cache or log devices

Expansion and connectivity

• PCIe slots:
  • 1x PCI-E 3.0 x16
  • 2x PCI-E 3.0 x8
  • 1x PCI-E 2.0 x4 (mechanical x8)
• Network interfaces: 2x RJ-45 10 Gb/s
• USB ports: 5x USB 3.0 (4x rear, 1x internal Type A)

Power and efficiency

• Power supplies: 2x hot-swap units
• Power rating: 1200 W total capacity
• Redundancy: yes, redundant PSU configuration
• Efficiency class: 80 Plus Titanium for optimized energy usage

Reliability and service

• Redundant power design for high availability
• ECC memory support to reduce risk of data corruption
• Hot-swap drive bays enabling service without system power-down
• Manufacturer warranty: 36 months

The Supermicro SuperStorage SSG-6029P-E1CR12L is suitable for scenarios that require a combination of high-capacity storage, strong compute resources and advanced I/O options, such as data-intensive applications, virtualization nodes, or tiered storage platforms, where reliability and energy efficiency are critical.
