Supermicro MBD-X10SRA-F Motherboard

The Supermicro MBD-X10SRA-F is an ATX-class workstation/server motherboard engineered for professional environments that require high memory capacity, PCIe bandwidth and long-term reliability. It is built around the LGA2011-3 socket and supports Intel Xeon E5-2600 v3/v4 processors up to 150W TDP, providing a stable platform for compute-intensive workloads.

With 8 DIMM slots, the board supports up to 1TB of ECC DDR4-2400 memory using 3DS LRDIMM modules or high-capacity ECC RDIMM. This allows deployment in scenarios where large memory footprints and data integrity are critical, such as virtualization, CAD/CAE, DCC, and technical computing.

• Processor support: LGA2011-3 socket for Intel Xeon E5-2600 v3/v4 series, single-socket configuration, max CPU TDP 150W
• Form factor: ATX, enabling integration into standard workstation and server chassis
• Memory subsystem: 8 DDR4 DIMM slots, up to 1TB ECC (3DS LRDIMM and ECC RDIMM), up to 2400 MHz, optimized for stability and error correction
• PCI Express expansion: 4x PCIe 3.0 x16 slots (configurable x16/x16/NA/x8 or x16/x8/x8/x8) plus 2x PCIe 2.0 x1 (mechanical x4), providing high bandwidth for GPUs, RAID controllers, high-speed I/O and specialized accelerator cards
• Storage and I/O flexibility: Multiple PCIe slots allow connection of dedicated NVMe, SAS/SATA and network adapters according to project requirements
• USB connectivity: 8x USB 3.0 ports (6 on rear I/O, 2 via internal headers) for high-speed external storage, peripherals and service access
• Networking: 2x RJ-45 1Gb/s Ethernet ports for redundant network paths, link aggregation or traffic separation between production and management networks
• Audio: Integrated ALC1150 HD Audio for workstation use cases requiring high-definition audio output
• Reliability: ECC memory support and a 36-month manufacturer warranty contribute to long-term operational stability in professional environments

The MBD-X10SRA-F is suitable for users building a robust single-socket Xeon platform with high memory capacity and multiple PCIe 3.0 x16 slots, for workloads such as engineering visualization, content creation, data analysis or virtualization hosts where reliability and expandability are prioritized.
