Supermicro MBD-X10DAI Motherboard

The Supermicro MBD-X10DAI is a high-performance E-ATX server and workstation motherboard designed for dual Intel Xeon E5-2600 v3/v4 processors in LGA2011 socket. It is optimized for memory-intensive and compute-heavy workloads, providing robust expandability and long-term platform stability.

Processor and power support

• Socket: LGA 2011
• CPU support: Intel Xeon E5-2600 v3/v4 family
• Number of CPU sockets: 2 (dual-socket)
• Max. supported CPU TDP: 160 W
• Processor included: No (CPUs required, sold separately)

Memory subsystem

• Memory slots: 16 DIMM
• Maximum memory capacity: up to 2 TB ECC 3DS LRDIMM or up to 1 TB ECC RDIMM
• Memory type: DDR4 ECC
• Supported memory speed: up to 2400 MHz (depending on CPU and module configuration)
• ECC support for enhanced reliability in professional environments

Expansion and connectivity

• Form factor: E-ATX
• PCI Express slots:
  • 3 x PCIe 3.0 x16
  • 2 x PCIe 3.0 x8
  • 1 x PCIe 2.0 x4 (mechanical x8)
• M.2 NVMe slots: 0
• USB ports:
  • 6 x USB 3.0 (2 rear, 4 optional)
  • 5 x USB 2.0 (4 optional, 1 Type A)
• Network interfaces: 2 x RJ-45 1 Gb/s

Reliability and usage scenarios

• Designed for professional server and workstation deployments
• High memory density for virtualization, databases and scientific computing
• Multiple PCIe 3.0 x16 slots for GPU, HBA, RAID or high-speed I/O adapters
• Dual 1GbE LAN for redundant or segmented network configurations
• 36-month manufacturer warranty for long-term operational continuity

The Supermicro MBD-X10DAI is a suitable platform for environments requiring dual-socket compute capability, large ECC memory configurations and extensive PCIe expansion, while maintaining a standard E-ATX form factor for compatibility with a wide range of chassis.
