Supermicro MBD-X13SAN-H Motherboard

Supermicro MBD-X13SAN-H is a high-performance 3.5" Single Board Computer (SBC) designed for demanding embedded and industrial applications. It is equipped with a soldered 12th Gen Intel® Core i7-1265UE processor, delivering 10 cores and 12 threads with a base frequency of 1.8GHz and an ultra-efficient 15W TDP.

• CPU: Integrated 12th Gen Intel® Core i7-1265UE (10C/12T, 1.8GHz, 12MB cache, 15W)
• Socket: FCBGA-1744 (CPU soldered on board)
• Memory: 2x DDR5-4800 SODIMM slots, supporting up to 64GB unbuffered non-ECC RAM
• Storage Expansion: 3x M.2 NVMe slots enable high-speed storage configurations
• Network: Dual 2.5GbE (2x RJ-45) for enhanced connectivity and network redundancy
• USB: 6x USB total (2 rear Type-A, 4 header), 2x USB 3.2 Gen2 Type-C with DP1.4a (ALT mode) support for versatile peripheral integration
• PCIe Slot: 1x PCIe 4.0 x4 SlimSAS for additional expansion
• Form Factor: Compact 3.5" board for space-constrained environments
• Warranty: 36 months manufacturer's warranty for reliability and peace of mind

This board is engineered for robust performance in compact systems, offering advanced connectivity, efficient power consumption, and extensive expansion capabilities. It is ideal for edge computing, industrial automation, and embedded system applications that require both performance and reliability.
