Supermicro MBD-X10SRM-TF Motherboard

The Supermicro MBD-X10SRM-TF is a microATX server-class motherboard designed for Intel Xeon E5-2600 v3/v4 processors in LGA 2011 socket. It targets compact, high‑reliability systems where stability, memory capacity and high‑speed networking are critical.

Processor and power support

• Socket: LGA 2011
• CPU support: Intel Xeon E5-2600 v3/v4 family
• Processor count: Single-socket configuration
• Max. CPU TDP: 145 W
• Processor included: No (CPU required, sold separately)

Memory subsystem

• Memory slots: 4 DIMM slots
• Maximum capacity: up to 512 GB total memory
• Memory type: ECC 3DS LRDIMM DDR4
• Supported speed: up to 2400 MHz† (depending on CPU and module configuration)

Expansion and connectivity

• Form factor: microATX – suitable for compact server and workstation chassis
• PCI Express slots:
  • 1 × PCI-E 3.0 x16
  • 2 × PCI-E 3.0 x8
• M.2 NVMe slots: 0 (no onboard M.2 interface)

Networking

• LAN interfaces: 2 × RJ-45 10 Gb/s ports
• Designed for high-throughput networking, virtualization nodes and storage-focused builds where dual 10GbE is required.

USB interfaces

• USB 2.0 ports: 6
  • 2 × rear panel
  • 4 × optional (via headers or accessories, depending on configuration)
• USB 3.0 ports: 5
  • 2 × rear panel
  • 1 × Type-A
  • 2 × optional

Reliability and warranty

• Manufacturer warranty: 36 months
• Platform oriented towards continuous operation and professional server environments, where long-term availability and serviceability are essential.

This motherboard is suitable for compact servers, virtualization hosts, and network appliances that require a single-socket Intel Xeon E5-2600 v3/v4 platform, high memory density with ECC support, and integrated dual 10GbE connectivity.
