Supermicro MBD-X11SSL-CF Motherboard

The Supermicro MBD-X11SSL-CF is a microATX server-class motherboard designed for stable and efficient operation with Intel Xeon E3-1200 v5/v6 processors on the LGA1151 socket. It is optimized for compact servers, network appliances, and technical workstations requiring ECC memory support and reliable 24/7 operation.

Processor and power support

• Socket: LGA 1151
• Supported CPU family: Intel Xeon E3-1200 v5/v6
• Number of CPU sockets: 1 (single-socket platform)
• Maximum CPU TDP: 80W
• CPU included: No (processor required separately)

Memory subsystem

• Memory slots: 4 DIMM
• Maximum capacity: 64GB
• Memory type: ECC UDIMM DDR4-2400 MHz
• ECC support enhances data integrity for server and professional workloads

Expansion and connectivity

• PCIe slots:
  • 1 × PCI-E x8 (mechanical x16 slot)
  • 1 × PCI-E x4 (mechanical x8 slot)
  • 1 × PCI-E 3.0 x1
• LAN interfaces:
  • 2 × RJ-45 1Gb/s for redundant or aggregated network links
• M.2 NVMe slots: 0 (storage expansion via other interfaces on the platform)

USB ports

• USB 2.0:
  • 6 total (2 rear, 4 optional)
• USB 3.0:
  • 5 total (2 rear, 1 Type A, 2 optional)

Form factor and reliability

• Form factor: microATX – suitable for compact server and workstation chassis
• Manufacturer warranty: 36 months
• Designed for continuous operation in professional environments where stability and uptime are critical

The Supermicro MBD-X11SSL-CF is an appropriate choice for administrators and integrators building space-efficient servers, gateway systems, or technical workstations that require ECC memory, dual Gigabit Ethernet, and flexible PCIe expansion without compromising on reliability.
