Supermicro MBD-X10DRi-LN4+ Motherboard

The Supermicro MBD-X10DRi-LN4+ is a dual-socket server motherboard engineered for high-reliability, memory-intensive and virtualized workloads. Built in the E.E. ATX form factor and based on the LGA 2011 socket, it supports Intel Xeon E5-2600 v3/v4 processors with a maximum TDP of 145 W per CPU.

This platform is designed for professional server and workstation deployments requiring high memory capacity, broad PCIe expansion and robust network connectivity.

• Processor support
  Dual LGA 2011 sockets for Intel Xeon E5-2600 v3/v4 processor family. The board does not include a processor in the package, allowing flexible CPU selection according to performance and power requirements. Maximum supported TDP is 145 W per processor, enabling deployment of high-core-count configurations.
• Memory subsystem
  Equipped with 24 DIMM slots, the motherboard supports up to 3 TB ECC 3DS LRDIMM or up to 768 GB ECC RDIMM. This high-density memory configuration is suitable for virtualization, in-memory databases, caching layers and other RAM-intensive applications that require capacity, stability and error correction.
• Expansion capabilities
  The board offers a versatile PCI Express layout for add-in cards:
  • 2 × PCI Express 3.0 x16 slots
  • 3 × PCI Express 3.0 x8 slots
  • 1 × PCI Express 2.0 x4 (in x8 slot)
  This configuration allows integration of multiple RAID controllers, HBAs, network adapters or GPU/accelerator cards, depending on workload requirements.
• Network connectivity
  Integrated networking includes 4 × RJ-45 1 Gb/s ports. Multiple gigabit interfaces enable link aggregation, network isolation between services or redundant connectivity for increased availability in server environments.
• USB interfaces
  The board provides a wide range of USB ports for system integration and service access:
  • 4 × USB 2.0 (2 rear + 2 optional)
  • 5 × USB 3.1 Gen1 (2 rear, 2 optional, 1 Type-A)
  The presence of a USB 3.1 Gen1 Type-A connector enhances flexibility for boot media, diagnostics or external storage.
• Storage considerations
  The motherboard offers 0 native M.2 NVMe slots. For NVMe or additional storage connectivity, dedicated PCIe adapters or controller cards can be used via the available PCI Express slots, allowing tailored storage architectures.
• Form factor and integration
  With an E.E. ATX form factor, the board is intended for compatible server chassis that support extended ATX server motherboards. This format enables dense component placement and extensive expansion while maintaining compatibility with professional rackmount and tower enclosures designed for enterprise use.
• Reliability and warranty
  The platform is targeted at continuous, long-term operation in data center or professional environments. The 36-month manufacturer warranty provides an additional layer of assurance for business-critical deployments.

Note: No processors or memory modules are included. Cooling, power supply and chassis must be selected according to system design, CPU TDP and deployment conditions.
