Supermicro MBD-X10DRD-IT Motherboard

Supermicro MBD-X10DRD-IT is a server-grade E-ATX motherboard designed for high-availability and high-density compute environments. It supports dual Intel Xeon E5-2600 v3/v4 processors, enabling scalable multi-core configurations for virtualization, storage, and compute-intensive workloads.

The board is optimized for stability, memory capacity and I/O bandwidth, making it suitable for professional server and data center deployments.

• CPU support: Dual LGA 2011 sockets for Intel Xeon E5-2600 v3/v4 family, up to 145W TDP per processor (CPU not included).
• Form factor: E-ATX, enabling integration in standard server and workstation chassis supporting this size.
• Memory subsystem: 8 DIMM slots with support for ECC memory modules, up to 1TB using 3DS LRDIMM, and compatibility with ECC RDIMM DDR4-2400 for improved reliability and data integrity.
• Expansion: 4x PCI Express 3.0 x8 slots providing high-bandwidth connectivity for RAID controllers, HBAs, network adapters or accelerator cards.
• Networking: 2x RJ-45 10Gb/s ports for high-throughput LAN or storage traffic, reducing the need for additional network adapters in many configurations.
• USB connectivity: 7x USB 2.0 ports (4 rear, 2 optional, 1 Type A) for peripheral devices, service access and embedded applications.
• Storage interfaces: No onboard M.2 NVMe slots, which favors traditional server storage layouts using add-in cards or other onboard connectors.
• Reliability: ECC memory support and server-class design help minimize downtime and data corruption risks in 24/7 environments.
• Warranty: 36-month manufacturer warranty for long-term deployment scenarios.

Application profile

This platform is targeted at technical users building or upgrading servers where memory capacity, dual-CPU scalability and 10GbE connectivity are critical. It is well suited for virtualization hosts, compute nodes, storage gateways and other infrastructure roles that require consistent performance and robust hardware-level reliability features.
