Supermicro MBD-X14SAE Motherboard
SKU:
MBD-X14SAE-O
$570.97/brutto
$464.20/netto
The Supermicro MBD-X14SAE is an ATX motherboard supporting Intel Core Ultra 9/7/5 Series processors (up to 125W TDP). It features 4 RAM slots, advanced USB connectivity including USB 4 and Thunderbolt 4, 2 M.2 NVMe slots, and PCIe 5.0 x16 expansion. Ideal for high-performance computing and professional workstations.
The Supermicro MBD-X14SAE motherboard is designed for demanding users requiring advanced performance and scalability. Featuring the ATX form factor, it supports single Intel Core Ultra 9/7/5 Series processors with a maximum TDP of 125W, ensuring compatibility with powerful CPUs for intensive workloads.
- Processor Support: Single socket, compatible with Intel Core Ultra 9/7/5 Series (max. 125W TDP)
- Memory: 4 DIMM slots for high-capacity RAM configurations
- Expansion: 1 PCIe 4.0 x4 slot, 2 PCIe 5.0 x16 slots (supporting up to 16/NA or 8/8 lanes; slot 3 supports bifurcation x4x4)
- Storage: 2 M.2 NVMe slots enable ultra-fast SSD storage solutions
- Connectivity: Comprehensive USB options: 3 USB 3.2 Gen2 (rear type A), 2 USB 3.2 Gen2x2 (1 rear type C, 1 via header), 2 USB 3.2 Gen1 (headers), and 1 USB 4 (rear type C, Intel® Thunderbolt™ 4)
- Reliability: Manufacturer warranty of 36 months
This motherboard is ideal for professional workstations, content creation, and high-performance computing tasks. The advanced PCIe 5.0 expansion and modern USB connectivity ensure compatibility with the latest peripherals and graphics cards, providing future-proofing for evolving system requirements.
MBD-X14SAE-O
Data sheet
- Rozmiar płyty:
- ATX
- Ilość gniazd procesorów
- 1
- Rodzina obsługiwanych procesorów
- Intel Core Ultra 9/7/5 Series Processor
- Procesor wbudowany w płytę
- Nie
- Max. TDP procesora
- 125W
- Liczba slotów RAM
- 4
- Porty USB
- 3 USB 3.2 Gen2 port(s) (3 rear type A) 2 USB 3.2 Gen2x2 port(s) (1 rear type C; 1 via header) 2 USB 3.2 Gen1 port(s) (2 headers) 1 USB 4 port(s) (1 rear type C Intel® Thunderbolt™ 4)
- Interfejs PCI
- 1 PCIe 4.0 x4, 2 PCIe 5.0 x16 (support up to 16/NA or 8/8; slot 3 support bifurcation x4x4
- Liczba złącz M.2 NVMe
- 2
- Gwarancja producenta
- 36 miesięcy
