Płyta główna Supermicro MBD-X11SSH-LN4F

Supermicro MBD-X11SSH-LN4F is a microATX server/workstation motherboard designed for stable 24/7 operation and efficient resource utilization in professional IT environments.

Processor and memory subsystem

• Socket: LGA 1151
• CPU support: Intel Xeon E3-1200 v5/v6 family (single socket)
• Max CPU TDP: 80 W
• RAM slots: 4 DIMM sockets
• Max memory capacity: 64 GB
• Memory type: ECC UDIMM DDR4-2400 MHz

The platform is optimized for Xeon E3 processors with ECC memory, providing improved data integrity for applications where reliability is critical.

Expansion and storage

• PCIe interfaces:
  • 2 × PCI Express 3.0 x8 (one in x16 slot)
  • 1 × PCI Express 3.0 x4 (in x8 slot)
• M.2 NVMe: 1 slot for high-performance NVMe SSD

The PCIe layout enables flexible configuration with RAID controllers, HBAs, network adapters or other expansion cards, while the M.2 NVMe slot allows low-latency storage deployment.

Network connectivity

• LAN ports: 4 × RJ-45 1 Gb/s

Four Gigabit Ethernet ports provide advanced networking scenarios such as link aggregation, redundancy or traffic separation, depending on system configuration and software.

USB connectivity

• USB 2.0: 6 ports (2 rear, 4 optional)
• USB 3.0: 5 ports (2 rear, 1 Type-A, 2 optional)

The combination of USB 2.0 and USB 3.0 ports supports both legacy peripherals and high-speed external devices.

Form factor and reliability

• Form factor: microATX
• Manufacturer warranty: 36 months

The microATX format enables deployment in compact server and workstation chassis while maintaining sufficient expansion capabilities. The 36‑month manufacturer warranty underlines its suitability for professional use cases where uptime and lifecycle are important.

Application scenarios

• Entry-level and mid-range servers
• Virtualization hosts (within platform limits)
• Network and storage appliances
• Technical and engineering workstations requiring ECC memory

Thanks to its server-class design and ECC memory support, the Supermicro MBD-X11SSH-LN4F is a solid base for systems where operational stability and predictable performance are key requirements.
