Płyta główna Supermicro MBD-X11SSH-CTF

Supermicro MBD-X11SSH-CTF is a microATX server-class motherboard designed for Intel Xeon E3-1200 v5/v6 processors in LGA1151 socket. It provides a stable platform for compact servers, storage appliances and network nodes where reliability and bandwidth are critical.

Processor and memory subsystem

• LGA1151 socket, single CPU configuration, max. TDP 80 W
• Support for Intel Xeon E3-1200 v5/v6 processor family (no CPU included)
• 4 DIMM slots, up to 64 GB ECC UDIMM DDR4-2400
• ECC support improves data integrity and reduces risk of silent data corruption in 24/7 workloads

Expansion and storage

• 1 x PCI Express 3.0 x8 for high-bandwidth adapters (e.g. RAID, HBA, accelerator)
• 1 x PCI Express x2 (mechanical x4 slot) for additional controllers or network cards
• 1 x M.2 NVMe slot for high-performance OS or cache SSD

Network and connectivity

• 2 x RJ-45 10 Gb/s network ports for high-throughput and low-latency communication
• USB interfaces: 6 x USB 2.0 (2 rear, 4 optional) and 5 x USB 3.0 (2 rear, 1 Type-A, 2 optional)
• Flexible USB layout simplifies integration of service ports, boot media and external devices

Operational benefits

• MicroATX form factor enables dense, cost-effective systems with standard chassis compatibility
• Server-grade design aimed at continuous, long-term operation
• Balanced feature set for file servers, small virtualization hosts, security appliances and edge computing nodes
• 36-month manufacturer warranty for predictable lifecycle planning

The Supermicro MBD-X11SSH-CTF is suitable wherever a compact, technically robust platform is required, combining ECC memory support, dual 10GbE and NVMe capability in a microATX format.
