Supermicro SuperServer SYS-E403-9D-12C-FN13TP
SKU:
SYS-E403-9D-12C-FN13TP
$2,979.60/brutto
$2,422.44/netto
The Supermicro SuperServer SYS-E403-9D-12C-FN13TP is a Box PC designed for high-performance applications. It features a single Intel Xeon D-2163IT processor with 12 cores and 24 threads, supports up to 512GB ECC RAM, and includes multiple storage and connectivity options such as SATA/SAS, M.2 NVMe, and high-speed network interfaces. Power supply is rated at 600W with 80 Plus Gold efficiency.
Supermicro SuperServer SYS-E403-9D-12C-FN13TP is a high-efficiency Box PC engineered for advanced computing environments. Designed for reliability and expandability, it addresses the requirements of data-intensive and network-centric workloads.
- Processor: Integrated Intel Xeon D-2163IT, 12 cores / 24 threads, 2.1GHz, 75W TDP
- Memory Support: 4 slots, up to 512GB ECC LRDIMM or 256GB ECC RDIMM, DDR4-2133MHz
- Storage Options: 4x 2.5" drive bays supporting SATA/SAS, plus 1x M.2 NVMe slot
- Expansion: 2x PCI-E 3.0 x16 or 2x PCI-E 3.0 x8, 1x PCI-E 3.0 x16 (full height, 3/4 length)
- Connectivity: 9x RJ-45 1Gb/s, 2x RJ-45 10Gb/s, 2x SFP+ 10Gb/s
- USB Ports: 2x USB 3.0 (front), 2x USB 2.0 (front)
- Power Supply: 600W, 80 Plus Gold certified, non-redundant
- Chassis: Box PC form factor
- Warranty: 36 months manufacturer warranty
This system is suitable for edge computing, network appliances, and virtualization tasks where high CPU density, memory bandwidth, and multiple network interfaces are essential. Its compact Box PC design allows flexible deployment in various environments.
SYS-E403-9D-12C-FN13TP
Data sheet
- Rodzaj obudowy
- Box PC
- Ilość gniazd procesorów
- 1
- Procesor wbudowany w płytę
- Tak
- Number of Processors
- 1
- Procesor
- Intel Xeon D-2163IT 12C/24T 2,1GHz 75W
- Liczba slotów RAM
- 4
- Maksymalna pamięć RAM
- 512GB ECC LRDIMM; 256 GB ECC RDIMM DDR4-2133MHz
- Zasilacz
- 600W
- Zasilacz redundantny
- Nie
- Wielkość kieszeni dyskowych
- 2,5"
- Liczba mocowań na dyski 2,5"
- 4
- Interfejs dysków
- SATA
- Porty USB
- 2x USB 3.0 (front) 2x USB 2.0 (front)
- Interfejs PCI
- 3x PCI-E 3.0 x16 (1x FH 3/4L) 2x PCI-E 3.0 x8
- Złącza internetowe
- 9x RJ-45 1Gb/s; 2x RJ-45 10Gb/s; 2x SFP+ 10Gb/s
- Liczba złącz M.2 NVMe
- 1
- Wydajność energetyczna
- 80 Plus Gold
- Gwarancja producenta
- 36 miesięcy
