Supermicro MBD-X10SRH-CF Motherboard

The Supermicro MBD-X10SRH-CF is a server-grade ATX motherboard designed for high-reliability and scalable x86 platforms. Based on the LGA 2011 socket, it supports Intel Xeon E5-2600 v3/v4 processors up to 145 W TDP, delivering a robust foundation for demanding compute and storage workloads.

With 8 DIMM slots and support for up to 1 TB ECC 3DS LRDIMM DDR4-2400 memory, the board is optimized for memory-intensive applications where stability and data integrity are critical.

Key technical parameters

• Socket / CPU support: LGA 2011; Intel Xeon E5-2600 v3/v4; maximum CPU TDP 145 W; no processor included in the package.
• Form factor: ATX, suitable for standard server and workstation chassis that support this format.
• CPU sockets: Single-socket configuration for focused per-core performance and simplified platform design.
• Memory subsystem: 8 DIMM slots; up to 1 TB ECC 3DS LRDIMM DDR4-2400, enabling high-capacity, error-correcting memory configurations.
• PCI Express expansion: 3 × PCIe 3.0 x8 (one in a physical x16 slot); 1 × PCIe 2.0 x2 (in a physical x4 slot); 2 × PCIe x4 in x8 slots (1 × PCIe 2.0; 1 × PCIe 3.0), supporting a wide range of RAID, HBA, NIC, and accelerator cards.
• USB connectivity: 8 × USB 2.0 (2 rear, 6 optional); 4 × USB 3.0 (2 rear, 1 optional, 1 Type A); 1 × eUSB header for flexible peripheral and service connectivity.
• Network interfaces: 2 × RJ-45 1 Gb/s Ethernet ports for redundant or aggregated network links.
• M.2 NVMe: No on-board M.2 NVMe slots.
• Warranty: 36-month manufacturer warranty.

Operational benefits

• High memory capacity and ECC support – up to 1 TB ECC DDR4-2400 enables deployment of memory-intensive services while maintaining data integrity.
• Flexible expansion – multiple PCIe 3.0 and 2.0 slots allow precise adaptation to storage, networking and controller requirements.
• Rich I/O – extensive USB 2.0/3.0 connectivity and eUSB header simplify integration of service tools and external devices.
• Network redundancy – dual 1 GbE interfaces support failover and link aggregation scenarios.
• Long-term availability – a 36-month warranty supports stable, long-life deployments.
