Supermicro MBD-X10DRL-C Motherboard

The Supermicro MBD-X10DRL-C is a server-grade ATX motherboard designed for dual-socket Intel Xeon E5-2600 v3/v4 platforms. It combines high memory capacity, robust storage capabilities and reliable network connectivity, making it suitable for virtualization, storage servers and general-purpose enterprise workloads.

Processor and performance

• Socket: LGA 2011 (dual-socket configuration)
• Supported CPU family: Intel Xeon E5-2600 v3/v4
• Maximum CPU TDP: 145 W
• Processor included: No (CPUs required separately)

Memory subsystem

• Number of DIMM slots: 8
• Maximum memory capacity: up to 1 TB
• Supported memory type: ECC 3DS LRDIMM DDR4
• Memory frequency: up to 2400 MHz

Expansion and connectivity

• Form factor: ATX
• PCIe slots: 2 × PCI-E 3.0 x8, 1 × PCI-E 3.0 x16
• M.2 NVMe slots: 0 (NVMe support requires add-in cards if needed)
• USB ports: 4 × USB 2.0 (2 rear + 2 optional), 3 × USB 3.0 (2 rear + 1 Type A)
• Network interfaces: 2 × RJ-45 1 Gb/s

Integrated storage controller

• Onboard SAS/SATA RAID: Broadcom 3108 controller with 2 GB cache
• Supported RAID levels: 0, 1, 5, 6, 10, 50, 60
• Designed for hardware-accelerated RAID and improved I/O consistency in storage-oriented deployments.

Reliability and service

• Manufacturer warranty: 36 months
• Server-class design focused on stability under continuous 24/7 operation.

The Supermicro MBD-X10DRL-C provides a balanced platform for multi-core Xeon processors, high-density ECC memory and hardware RAID, enabling efficient consolidation of compute and storage tasks in rack or tower server configurations.
