Supermicro MBD-X10DRD-iTP Motherboard

Supermicro MBD-X10DRD-iTP is a high-performance dual-socket E-ATX server motherboard engineered for Intel Xeon E5-2600 v3/v4 platforms. It is designed for demanding data center, virtualization and enterprise workloads that require high memory capacity, I/O flexibility and reliable 24/7 operation.

Key technical parameters

• CPU socket: LGA 2011, compatible with Intel Xeon E5-2600 v3/v4 family
• CPU support: Dual-socket configuration (2 processors, not included)
• Max CPU TDP: up to 145 W per processor
• Form factor: E-ATX, suitable for compatible server chassis

Memory subsystem

• Memory slots: 8 DIMM sockets
• Maximum capacity: up to 1 TB
• Supported modules: ECC 3DS LRDIMM and ECC RDIMM
• Standard and speed: DDR4, up to 2400 MHz (DDR4-2400)

This configuration enables high memory density and reliability, suitable for virtualized environments, in-memory applications and database servers that require error-correcting capabilities.

Expansion and connectivity

• PCI Express: 4 x PCIe 3.0 x8 slots for RAID controllers, HBAs, network adapters or accelerator cards
• USB ports: 7 x USB 2.0 (4 x rear, 2 x optional, 1 x internal Type A)
• Network interfaces: 2 x SFP+ 10 Gb/s for high-bandwidth, low-latency connectivity
• M.2 NVMe slots: none onboard

The dual 10GbE SFP+ interfaces allow integration into high-speed network infrastructures, making the board suitable for storage servers, virtualization clusters and application servers with intensive network traffic.

Reliability and service

• Manufacturer warranty: 36 months

The robust design and extended warranty period make this motherboard a solid foundation for long-life server deployments where stability and predictable operation are critical.

Application scenarios

• Virtualization hosts and private cloud nodes
• Database and application servers requiring high memory capacity
• Network and storage servers utilizing 10GbE connectivity

Thanks to its dual-socket support, high memory ceiling and 10GbE networking, the Supermicro MBD-X10DRD-iTP is well-suited as a platform for scalable, multi-role server systems.
