Supermicro MBD-H11SSL-C Motherboard

The Supermicro MBD-H11SSL-C is an ATX server-class motherboard designed for single-socket AMD EPYC platforms. Based on the SP3 socket and supporting AMD EPYC 7001/7002 processor families, it provides a stable foundation for compute-intensive and storage-focused deployments.

Processor and memory subsystem

• Socket: SP3, single-CPU configuration for AMD EPYC 7001/7002 series
• Memory slots: 8 DIMM sockets
• Maximum memory: up to 2TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
• ECC support for enhanced data integrity in server and workstation environments

Expansion and storage

• PCIe interface: 3 × PCI-E 3.0 x16 and 3 × PCI-E 3.0 x8 slots for network, storage or accelerator cards
• M.2: 1 × M.2 NVMe slot for high-performance SSDs
• SAS controller: integrated Broadcom 3008 SAS3 RAID controller
• RAID levels: hardware support for RAID 0, 1, 10

Connectivity

• LAN: 2 × RJ-45 1Gb/s Ethernet ports for redundant or aggregated network links
• USB ports:
  - 5 × USB 3.0 (2 rear, 2 optional, 1 Type-A)
  - 4 × USB 2.0 (2 rear, 2 optional)

Reliability and lifecycle

• Processor included: not included (CPU purchased separately)
• Form factor: ATX, compatible with a wide range of server and workstation chassis
• Manufacturer warranty: 36 months

The Supermicro MBD-H11SSL-C is targeted at environments that require high memory capacity, robust I/O expansion and integrated SAS3 RAID capabilities. Its technical feature set makes it suitable as a platform for virtualization hosts, storage servers or compute nodes where stability and long-term availability are critical.
