Supermicro MBD-H11DSI Motherboard

The Supermicro MBD-H11DSI is a high-performance server motherboard designed for demanding virtualisation, database and HPC workloads. Built on the E-ATX form factor, it provides extensive expandability and memory capacity for modern data center and enterprise environments.

Processor and power capabilities

• Socket: Dual SP3 for AMD EPYC 7001/7002 series
• Number of CPU sockets: 2 (dual-processor configuration)
• Maximum supported CPU TDP: 240 W per processor
• CPU included: No (processors sold separately)

Memory subsystem

• Number of DIMM slots: 16
• Maximum memory capacity: up to 4 TB
• Supported memory types: 3DS ECC DDR4-3200 RDIMM/LRDIMM
• ECC support for improved data integrity and system stability

Expansion and storage

• PCI Express slots: 2x PCIe 3.0 x16, 3x PCIe 3.0 x8
• Suitable for RAID controllers, high-speed NICs, HBAs and GPU/accelerator cards (depending on system design)
• M.2 storage: 1x M.2 NVMe slot for high-performance SSD

Network and connectivity

• LAN: 2x RJ-45 1 Gb/s Ethernet interfaces
• USB ports: 2x USB 3.0 (rear)
• USB ports: 4x USB 2.0 (2x rear, 2x optional, depending on chassis/front-panel configuration)

Form factor and integration

• Motherboard size: E-ATX
• Optimised for rackmount and tower server chassis compatible with E-ATX boards
• Designed for continuous 24/7 operation in professional IT environments

Reliability and warranty

• Manufacturer warranty: 36 months
• Enterprise-class design for high availability and long lifecycle deployments

The Supermicro MBD-H11DSI provides a robust platform for multi-core AMD EPYC processors, large memory footprints and flexible expansion options, making it suitable for compute-intensive, memory-hungry and virtualised workloads in professional server infrastructures.
