Supermicro CSE-815TQC-605WB

The Supermicro CSE-815TQC-605WB is a 1U rackmount chassis designed for high-density server environments requiring reliable power delivery and flexible storage configuration. It combines a 600W 80 Plus Platinum power supply with a 12Gb/s SAS/SATA backplane to support modern enterprise-class drives.

Key technical parameters

• Form factor: 1U rackmount chassis
• Power supply: 600W
• Power redundancy: non-redundant (single PSU)
• Energy efficiency: 80 Plus Platinum
• Drive bay type: 3.5" with the option to install 2.5" drives using an additional adapter (not included)
• Hot-swap bays: 4 x 3.5" front-access hot-swap bays
• Backplane: SAS/SATA 12Gb/s
• Manufacturer warranty: 36 months

Storage and connectivity

• 12Gb/s SAS/SATA backplane enables the use of both SAS and SATA drives, allowing flexible configuration for performance- or capacity-oriented workloads, depending on the installed controllers and drives.
• Four hot-swap bays simplify drive replacement and expansion without shutting down the system, which is beneficial in environments requiring high availability and minimized downtime.
• Support for 2.5" drives via adapter (optional) allows the use of SSDs or smaller form factor HDDs, providing additional options to optimize I/O performance and storage density.

Power and efficiency

• 600W power budget is suitable for typical 1U server configurations, depending on the selected motherboard, CPUs, memory, and peripheral cards.
• 80 Plus Platinum certification indicates high power conversion efficiency, which can contribute to lower power losses and reduced heat output under typical loads.
• Non-redundant PSU design simplifies the power subsystem and may be appropriate for scenarios where external power redundancy is provided at the rack or facility level.

Operational benefits

• Compact 1U form factor supports dense rack deployments in data centers and server rooms with limited vertical space.
• Hot-swap drive access can reduce service time during maintenance and drive replacement operations.
• 36-month manufacturer warranty provides a defined support window for planning lifecycle and maintenance strategies.

This chassis is intended to be integrated with compatible server motherboards, storage controllers, and drives according to system design requirements. Specific performance and capacity characteristics depend on the chosen components and are not defined by the chassis alone.
