Supermicro CSE-745TQ-R920B

Supermicro CSE-745TQ-R920B is a high-performance tower server chassis designed for demanding, continuous operation. It combines redundant power, extensive storage capacity and efficient cooling in a robust E-ATX platform.

Power and reliability

• Power supply: 920W redundant (2x PSU) for increased availability and fault tolerance.
• Efficiency: 80 Plus Platinum – optimized power usage and reduced heat output.
• Warranty: 36-month manufacturer warranty for long-term operational security.

Storage subsystem

• Drive bays: 8x 3.5" hot-swap bays for high-capacity HDDs.
• Flexibility: possibility to install 2.5" drives using an additional adapter (not included).
• Backplane: SAS/SATA 6Gb/s, enabling integration with a wide range of enterprise drives.

Expansion and connectivity

• Motherboard support: E-ATX form factor, suitable for advanced server and workstation platforms.
• Expansion slots: 7 slots for add-on cards such as RAID, networking or accelerator cards.
• 5.25" bays: 3 external bays for optical drives or additional front-access devices.
• Front panel I/O: 2x USB 2.0 for service access and peripheral connectivity.

Cooling and airflow

• Fans: 5 integrated fans for stable internal airflow and temperature control.
• Optimized layout to support continuous, high-load operation of server components.

This chassis is suitable for building robust server or storage systems where high availability, redundant power and scalable storage capacity are key requirements.
